Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Fan Current (115 Vac)
0.2 AMPS
Form Factor Rms/avg
≤ 1.01
Internal Heat Dissipation (watts)
75 W
Main Dc Bus Voltage
225 VDC (Min), 360 VDC (Max)
Maximum Velocity Capability (14-bit)
3000 RPM
Motor Current Ripple Frequency
20.0 kHz ±10%
Output Current (rms/phase)
10.0 A Cont, 20.0 A Peak (2s)
Output Kva (@ 325 Vdc Bus)
4.0 KVA Cont, 8.0 KVA Peak
Position Feedback Resolution Options
12, 14, or 16-bits
Pwm Switching Frequency
10.0 kHz
Resolver Excitation Frequency
8.5 kHz
Safety Relays
Includes hardware watchdog for fault monitoring
System Resolution (counts Per Revolution At 16-bit)
65536 counts
Temperature Specifications
Rated for 45°C ambient operation
Unregulated Logic Bus
±15-20 VDC @ 0.25 AMPS, +8-12 VDC @ 1.00 AMPS
