The BEL-090-06 is a DC servo drive manufactured by Copley Controls, part of the Accelnet CanOPEN Modules. It operates on 14–90 V DC delivering 3 A DC (2.1 A RMS) continuous and 6 A DC peak, supporting CSP, CSV, CST modes. Communication options include EtherCAT and RS-232. Weighing 0.77 kg with heatsink, it features SIL 3 STO and comprehensive HV OV/UV, overtemp, short protections.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Communications
EtherCAT, RS-232
Continuous current
3 A DC (2.1 A RMS) per phase
Control modes (basic)
CSP, CSV, CST
Dimensions with heatsink
5.08 x 3.41 x 3.39 in (129 x 86.6 x 86.1 mm)
Feedback (absolute BiSS)
BiSS B&C
Feedback (absolute)
SSI; EnDat; Absolute A (Tamagawa, Panasonic, Sanyo Denki)
Feedback (incremental)
Digital quad A/B; analog Sin/Cos; Panasonic
Feedback (resolver)
Requires -R option
Functional safety
IEC 61508-1, IEC 61508-2, IEC 61800-5-2
I/O analog
1 reference input, 12-bit
I/O digital
6 HS in, 1 temp in, 4 opto in, 3 opto out, 1 brake out
Peak current
6 A DC (4.24 A RMS), ±5%
Positioning modes
Interpolated position, Homing, Camming, Gearing, Indexer
Power output
+5 V DC, 500 mA max (thermal & short‑circuit protected)
Profile control modes
PP/PV/PT
Protections
HV OV/UV; over temp; short; I2t; feedback loss
Safe Torque Off (STO)
SIL 3, Cat.3, PL d
Voltage range
14–90 V DC
Weight with heatsink
1.70 lb (0.77 kg)
