S image of BH-622-B-99-270

BH-622-B-99-270

by Kollmorgen
$1,374.97 - $1,374.97
$1,374.97
$1,374.97 - $1,374.97
$1,374.97

In Stock, Ships Fast

The BH-622-B-99-270 servomotor, created by Kollmorgen, is a low inertia piece from the GOLDLINE brand. Working with a S610 SERVOSTAR servo amplifier, this Class H insulated device, meets DIN 57530 specifications. With a peak current rating of 37.7A and a maximum length of 355.6mm (including brake), it features a rotor with 10.3kgcm2 inertia. The installation requires proper EMC shielding and requires the motor flange and surroundings to ensure good heat transfer, not exceeding 65°C flange temperature. It features a phase-to-phase winding inductance of 32mH and resistance of 1.91 Ohms, with shielded motor cables having a 4 x 2.5mm2 area. The motor leads, ideal for trailing, withstand a million bending cycles and have less than 150pF/m capacitance. The motor comes with integrated thermal contact windings and weighs 16.8kg. The high radial force makes it suitable for high dynamics requirements.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Model

BH-622-B-99-270

Product Type

Low Inertia Servomotor

Insulation Class

Class H according to DIN 57530 specification

Companion Amplifier

S610 SERVOSTAR servo amplifier

Peak Current Rating

37.7A

Maximum Length

355.6mm (brake included)

Rotor Moment of Inertia

10.3kgcm2

Flange Maximum Temperature

65°C

Winding Inductance

32mH phase-to-phase

Winding Resistance

1.91 Ohms phase-to-phase

Motor Leads Cable Cross-sectional Area

4 x 2.5mm2

Motor Lead Life

One million bending cycles

Motor Lead Capacitance

Less than 150pF/m

Motor Sheathing

Polyurethane

Core Insulation Material

Polyteraphtalate

Post-use Cool Down Temperature

Less than 40°C

Weight

16.8kg

Thermal Time Constant

28min

Motor Housing Earthing Requirement

To a protective earth busbar inside switch cabinet
