BK1250

Original price $1,065.75 - Original price $1,065.75
Original price
$1,065.75
$1,065.75 - $1,065.75
Current price $1,065.75
In Stock, Ships Today
Request a quote
The Beckhoff BK1250 is an EtherCAT Bus Coupler designed for constructing control systems by blending standard Bus Terminals (KLxxxx) and EtherCAT Terminals (ELxxxx) within a bus station. The device, enclosed in terminal housing, requires no cables for operations and enables the creation of cost-effective, compact control solutions without additional hardware. The BK1250, utilized on a DIN-rail, can combine over 300 standard Bus Terminals and supports 64 K-Bus Terminals per unit. With a K-bus extension, it can manage up to 255 terminals. Unlike the BK1120 and BK1150 models, the BK1250, lacking a physical Ethernet port, utilises E-bus contacts for intra-bus connections. The device requires a 24VDC power supply, drawing a maximum current of 200 mA, and is mounted on a 35 mm mounting rail as defined by EN 60715. The front panel houses power supply spring terminals, diagnostic LEDs along with LEDs indicating the I/O Run and I/O Error status of the K-bus. For safety, a protective earth power contact can ground up to 125 A short-circuit current.
30 Day Warranty
Technical Specifications
  • Manufacturer: Beckhoff
  • Product Type: EtherCAT Bus Coupler
  • Model: BK1250
  • Terminal Housing: Yes
  • Cable Requirement: No
  • Deployment: DIN-rail with E-bus terminals on the left and K-bus terminals on the right
  • Compatibility: More than 300 standard Bus Terminals
  • Channel Capacity: 64 x K-Bus Terminals (extendable up to 255 terminals with K-bus extension)
  • Physical Ethernet Port: No
  • Control Capacity: All associated Bus Terminals
  • Power Supply: 24VDC
  • Current Draw: Maximum 200mA
  • Mounting: 35 mm mounting rails (EN 60715 standard)
  • Additional Features: Power supply spring terminals, diagnostic LEDs, I/O Run status and I/O Error status indicators, Protective earth power contact (up to 125 A short-circuit current)
