S image of BK9050

BK9050

by Beckhoff
$676.06 - $759.25
$676.06
$676.06 - $759.25
$676.06

In Stock, Ships 1 - 3 Days

The Beckhoff BK9050 is a versatile EtherCAT bus coupler designed for efficient automation tasks, supporting fast data transfer rates of 10/100 Mbit/s. It accommodates up to 64 bus terminals, expandable to 255 with the K-bus extension, making it suitable for larger systems. The BK9050 manages 512 bytes each for input and output on the fieldbus, capable of handling 1,020 digital and 128 analog peripheral signals. Configurable via KS2000 software, it simplifies setup and integration. It supports protocols such as TwinCAT ADS, Modbus TCP, and Beckhoff real-time Ethernet for compatibility with diverse control systems. The device includes an RJ45 Ethernet interface and employs 4 x 2 twisted pair copper cabling, with automatic data rate detection. Operating on a 24 V DC power supply, it has a 70 mA input current plus K-bus current, up to 500 mA, and supports a 1750 mA current supply for the K-bus, with power contact handling up to 24 V DC and 10 A.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Beckhoff

Series

BK EtherCAT Bus Coupler

Model

BK9050

Data Transfer Rate

10/100 Mbit/s

Bus Terminals Capacity

64 (up to 255 with K-bus extension)

Fieldbus I/O Capacity

512 bytes input/output

Digital Peripheral Signals

1,020

Analog Peripheral Signals

128

Configuration Software

KS2000

Supported Protocols

TwinCAT ADS, Modbus TCP, Beckhoff real-time Ethernet

Ethernet Interface

1 x RJ45

Cable Type

4 x 2 twisted pair copper

Cable Categories

Category 3 (10 Mbit/s), Category 5 (100 Mbit/s)

Transmission Rate Recognition

Automatic

Power Supply

24 V DC

Input Current

70 mA plus K-bus current

Maximum Input Current

500 mA

Current Supply for K-bus

1750 mA

Power Contacts Handling

Up to 24 V DC and 10 A

Starting Current

Approximately 2.5 times continuous current

Recommended Fuse

≤ 10 A
