S image of BPL-090-14

BPL-090-14

by Copley Controls
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message

The Copley Controls BPL-090-14 drive is part of the Accelnet CanOPEN Modules series, designed for precise motion control in industrial automation systems. This compact module supports a continuous current of 7 A and accepts a supply voltage range of 14 to 90 VDC for versatile power integration. With a 12-bit resolution, the BPL-090-14 ensures high-accuracy position, speed, and torque control. Its primary function is to translate CANopen DS-402 commands into reliable motor drive output for demanding applications.

Featuring a peak current of 14 A DC (9.9 A RMS) ", the BPL-090-14 excels in handling transient loads with ease. The drive offers multiple feedback options including incremental encoders, Hall sensors, and resolver support for seamless integration with various motor types. Safety is enhanced by the Safe Torque Off (STO) function rated to SIL 3, Category 3, PL d, while built-in protection guards against short circuits, over-temperature, and feedback loss. Configuration is streamlined via the RS-232 interface and CME 2TM software.

Built to operate from 0 to +45 °C and to survive storage conditions from °C, this module delivers robust performance under varied environmental conditions. Its small footprint—5.08 x 3.41 x 3.39 in with heatsink or 5.08 x 3.41 x 1.99 in without—optimizes panel space while the lightweight design (0.77 kg with heatsink) simplifies installation. Certified to UL 61800-5-1, TUV IEC 61508, and ISO 13849-1, and compliant with RoHS, the BPL-090-14 meets global safety and environmental standards. In industrial settings, its efficient CANopen communication, high protection levels, and precise control translate into improved system uptime, reduced maintenance, and superior process reliability.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Auxiliary HV Supply Voltage

+14 to +90 Vdc (optional)

Certifications

UL 61800-5-1, TÜV IEC 61508, ISO 13849-1

Communication Interface

RS-232

Continuous Current (per phase)

7 A DC (5 A RMS)

Dimensions with heatsink

5.08 x 3.41 x 3.39 in

Dimensions without heatsink

5.08 x 3.41 x 1.99 in

Feedback Support

Incremental encoders, Hall sensors, resolver

Operating Temperature

0 to +45 °C

Peak Current (per phase)

14 A DC (9.9 A RMS) ±5%

Protection

Short circuits, over-temperature, feedback loss

Resolution

12-bit

Safe Torque Off (STO)

SIL 3, Category 3, PL d

Signal Protocol

CANopen

Storage Temperature

-40 to +85 °C

Weight with heatsink

1.70 lb (0.77 kg)

Weight without heatsink

0.75 lb (0.34 kg)
