S image of BRE-5101-3028-A-13-91

BRE-5101-3028-A-13-91

by Kollmorgen
$1,086.25 - $1,086.25
$1,086.25
$1,086.25 - $1,086.25
$1,086.25

In Stock, Ships 1 - 3 Days

The BRE-5101-3028-A-13-91 from Kollmorgen offers a rated power of 13.9 kW and peak torque of 170.0 lb-ft. Part of the Kollmorgen Goldline B and BH Motors series, it spins up to 2000 RPM and delivers continuous torque of 61.5 lb-ft. The design also features a peak line current of 147.0 Amps RMS and a rotor inertia of 0.04415 kg-m².

It has a line-to-line DC resistance of 0.129 Ω and inductance of 7.2 mH. It delivers 18.6 HP. Motor supports up to 250 V RMS for versatile use.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Continuous Torque (stall) At 25°c (tc)

61.5 lb-ft / 83.4 N-m

Continuous Torque (stall) At 40°c (tc)

58.0 lb-ft / 78.6 N-m

Dc Resistance At 25°c (line-to-line)

0.129 Ohms

Horsepower (hp Rated)

18.6 HP

Inductance (line-to-line) ±30%

7.2 mH

Max Line-to-line Volts (vmax)

250 Volts RMS

Max Operating Speed (n Max)

2000 RPM

Peak Line Current (ip)

147.0 Amps RMS

Peak Torque (tp)

170.0 lb-ft / 230.0 N-m

Rated Power (kilowatts)

13.9 kW

Rotor Inertia (jm)

0.04415 kg-m²

Speed At Rated Power (n Rated)

2000 RPM

Static Friction (tf)

0.67 lb-ft (0.91 N-m)

Thermal Resistance At Stall (rth)

0.17 °C/Watt

Torque Sensitivity (stall)

1.21 lb-ft/Amp RMS (1.65 N-m/Amp RMS)
