BTV01.4CA-32T-50D-AS-DL-FW
The BTV01.4CA-32T-50D-AS-DL-FW terminal is a high-performance member of the BTV01 Visualization Terminals family from Bosch Rexroth Indramat, engineered for demanding industrial automation environments. This unit features a vivid 15" TFT LCD display with 1024 x 768 pixel resolution, delivering crisp graphical interfaces and detailed process visualization. At its core, the system integrates an Intel Pentium 200 MHz, MMX processor combined with 32 MB of main memory, ensuring responsive control and rapid data handling. A standard 3.5 in, 1.44 MB floppy disk drive and a minimum >=500 MB hard drive capacity provide both legacy compatibility and ample storage for application software and logging. The terminal’s front panel protection rating of IP65 guarantees reliable operation in dusty or washdown scenarios without sacrificing accessibility or visibility.
Performance is further enhanced through a versatile array of interfaces and expansion options. Connectivity includes one RS232 interface, one SIS interface (RS232+RS485), a parallel interface, and a VGA interface, enabling seamless integration with PLCs, drives, and peripheral devices. Two external keyboard ports support flexible input configurations, while the built-in full 70-key keyboard with 10 function and 8 machine keys streamlines user interaction and NC setup. The architecture accommodates two ISA bus slots plus three general expansion slots (one dedicated to the CPU card and another to interface modules), facilitating future upgrades or custom I/O additions. Despite a typical heat loss of 65 W (max 200 W), integrated cooling and ventilation maintain optimal thermal conditions, supporting continuous 24/7 operation. System power is managed via an autoranging 115/230 VAC ±15% supply, simplifying installation across diverse facilities.
Reliability and adaptability are central to the design, with housing rated IP20 per DIN 40050/IEC 529 standards for internal components and an operational temperature window from +5°C to +45°C. For transportation and storage, the terminal tolerates extremes between -20°C and +60°C, ensuring robust performance throughout the equipment lifecycle. Weighing approximately 8 kg, the compact chassis allows straightforward mounting on cabinets or control panels without imposing significant structural demands. Built-in cooling, front-panel IP65 sealing, and field-proven Bosch Rexroth Indramat quality make the BTV01.4CA-32T-50D-AS-DL-FW ideal for industrial automation, HMI deployment, process control, and batch management applications that require dependable visualization and user interaction under challenging conditions.
