BTV30.2CA-64R-11C-D-FW

Request a quote
The BTV30.2CA-64R-11C-D-FW is a robust, PC-based machine control terminal by Bosch Rexroth Indramat. Measuring 372x335x209 mm and weighing 10.5 kg, it features a 640x480 pixel LCD, 16 machine control keys, and a durable aluminum front panel. The terminal is powered by a Pentium processor with 64 MB of storage memory, 4 MB video memory, and a 1.2 GB hard disk. It is equipped with several slot cards and multiple interfaces including Ethernet, printer, and VGA connections. The product operates on a nominal voltage of AC 115-230V, 50-60Hz and has a mountable 3.5 or 1.44 MB disk drive. This professional-grade operator panel in the BTV20 family, boasts of an IP65 rating at the front when the disk flap closes, ensuring durability and protection from external impact. Note: An export certificate is mandatory for this product.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Model: BTV30.2CA-64R-11C-D-FW
  • Dimensions: 372x335x209 mm
  • Weight: 10.5 kg
  • Screen Type: 640x480 pixel LCD
  • Keys: 16 machine control keys
  • Front Panel Material: 4mm aluminum
  • Processor: Pentium processor 200 MHz
  • Storage Memory: 64 MB
  • Video Memory: 4 MB
  • Hard Disk Size: 1.2 GB
  • Slot Cards: 4/ISA, 3xPCI, 1xPCI/ISA
  • Interfaces: Ethernet, LPT1 Centronics printer, 1 x RS 232 COM1, VGA, 1 x RS232/RS485 COM2
  • Connecting Voltage: AC 115-230V, 50-60Hz
  • Disk Drive: 3.5 or 1.44 MB
  • Function Mode: MTC
  • Memory Capacity: 64 MB
  • Keyboard: 16 machine function keys
  • Protection Rating: IP65 when disk flap closed
  • Mandatory Documentation: Export certificate required.
