BZM01.1-01-07

Original price $436.62 - Original price $1,173.95
Original price
$436.62
$436.62 - $1,173.95
Current price $436.62
The BZM01.1-01-07 auxiliary bleeder module, produced by Bosch Rexroth Indramat, is a lightweight unit designed to be installed within a control cabinet and connected to the manufacturer's DKC drive controllers. This module, which weighs merely 4.08kg, facilitates connection support for up to six drive controllers simultaneously. Its function is activated when the controller's regenerative power exceeds 0.15kW. The bleeder's specifications include a continuous bleeder output of 1kW, a DC bus nominal voltage of 700V, and a 24V connection drawing a current of 90mA. The unit comes with a green H1 LED and red H2 LED indicators, an S1 reset button, a six-pin ready-to-operate contact, and a four-pin connector. The product, which offers a peak bleeder output and maximum feedback energy of 40kW, can be delivered to your chosen destination worldwide.

Contact Us

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer


Bosch Rexroth Indramat

Product


BZM01.1-01-07 auxiliary bleeder module

Component Use


Drive Controllers

Connection Type


DC bus circuit

Drive Controller Support


Maximum of six drive controllers

Weight


4.08kg

Terminal Style


Screw-down push-in terminals

Product Size


210 x 333 x 233mm

Continuous Bleeder Output


1kW

LED Indicators


H1 green, H2 red

Reset Button


S1

DC Bus Voltage


700V

Current Consumption


90mA

Feedback Energy


40kW

Peak Bleeder Output


40kW
