S image of C6525-1003-0030

C6525-1003-0030

by Beckhoff
$4,790.26 - $4,790.26
$4,790.26
$4,790.26 - $4,790.26
$4,790.26

In Stock, Ships Fast

The Beckhoff C6525-1003-0030 industrial PC from the C6 Industrial PC Units series delivers robust performance in harsh environments, featuring an external IP65 and internal IP20 protection class and enhanced shock resistance (5 g, 30 ms) and vibration resistance (10–58 Hz: 0.035 mm; 58–500 Hz: 0.5 g). Powered by 24 VDC (22–30 V), it consumes ~90 W in basic configuration. Measuring 330 × 275 × 82 mm and weighing 4.74 kg, it operates from 0 to 45 °C ambient (up to 55 °C internal) with up to 95% non-condensing humidity. Connectivity includes 2× RJ45 (100/1000BASE-T) Ethernet ports, 4× USB 2.0 ports, 1× RS232 serial port, and 1× DVI output, complying with EMC EN 61000-6-2/6-4 for industrial automation.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Dimensions

330 × 275 × 82 mm

DVI Port

1 DVI (Digital Visual Interface)

EMC Standards

EN 61000-6-2; EN 61000-6-4

Ethernet Ports

2 × RJ45 (100/1000BASE-T)

Impact Shock Resistance

5 g, 30 ms

Internal Ambient Temperature

0 to 55°C

Max Humidity

95% (non-condensing)

Operating Ambient Temperature

0 to 45°C

Power Consumption

~90 W (basic config)

Power Supply Voltage

24 VDC (22–30 V)

Protection Class

IP65 (external); IP20 (internal)

Serial Port

1 × RS232 (9-pin D-sub)

USB Ports

4 × USB 2.0

Vibration Shock Resistance

10–58 Hz: 0.035 mm; 58–500 Hz: 0.5 g

Weight

4.74 kg
