C6640-0030
by Beckhoff
The Beckhoff C6640-0030 Industrial PC is a high-performance member of the C6 Industrial PC Units family designed for demanding automation tasks. Equipped with an Intel® configurable processor and an ATX motherboard, it delivers scalable computing power in a compact form factor. With a protection rating of IP20, the unit is engineered to withstand industrial environments. Key features include robust vibration resistance of 5 m/s² and shock resistance of 5 G, ensuring reliable operation under dynamic mechanical stress.
In terms of connectivity and integration, the C6640-0030 offers a comprehensive set of interfaces: LAN (2x), USB (4x), DVI (2x), PS/2, RS232, DisplayPort, and Audio connections. Storage is provided via a 3.5-inch hard disk slot, and dimensions of 371 x 336 x 198 mm keep the device compact yet serviceable. Power options include 100–240 VAC (max. 3 A, 50–60 Hz) or 22–30 VDC (24 VDC), enabling flexible deployment across varied industrial power infrastructures.
Built for enduring performance, this Industrial PC operates within an ambient temperature range of 0 °C to +55 °C and can be stored between –25 °C and +65 °C. It tolerates up to 95% relative humidity (no condensation), meeting stringent environmental demands. Compliance with CE, FCC, UKCA, and EAC standards underscores its adherence to global safety and performance requirements. With reliable protection, extensive interfaces, and rugged design, the C6640-0030 enhances productivity and uptime in industrial automation applications.
