series image of C6915-0000

C6915-0000

by Beckhoff
$1,750.48 - $1,750.48
$1,750.48
$1,750.48 - $1,750.48
$1,750.48
In Stock, Ships 3 - 5 Days
The Beckhoff C6915-0000 Industrial PC features a compact, user-friendly design with front-facing connections. Powered by an Intel Atom quad-core processor, it operates with a TwinCAT 3 performance class of TC3: 40. This device, with its fanless design and passive cooling mechanism using internal cooling fins, is space-efficient and requires minimal air circulation. It includes a 1GB DDR2 RAM (expandable up to 2GB), an on-board Intel GMA 500 graphics adapter and a DVI-D connector. Additional features include a lithium battery, a Compact Flash slot, and an integrated power supply unit with 27V/1.4A UPS output for screen display maintenance during power outages. For setup, ensure a low impedance connection between the PC housing earthing point and the central control cabinet wall earthing point. Prevention against extreme environmental conditions and mechanical stress during transport is mandatory.
30 Day Warranty
Technical Specifications
  • Manufacturer: Beckhoff
  • Model Number: C6915-0000
  • Device Type: Industrial PC
  • Housing Type: Compact
  • Processor: Intel Atom quad-core
  • Motherboard Size: 3.5-inch
  • Cooling Mechanism: Passive (internal cooling fins, no external fan)
  • TwinCAT 3 Performance Class: TC3: 40
  • Design: Fanless
  • Battery: Lithium
  • Storage Expansion: Compact Flash card slot
  • RAM: 1GB DDR2 (expandable up to 2GB)
  • Graphics Adapter: On-board Intel GMA 500
  • Connector Type: DVI-D
  • Environmental Tolerance: Protected against heat, moisture, dust
  • Ventilation Requirement: 5cm of free space at top and bottom, ventilation slots must not be covered
  • Power Supply: Integrated with a 27V/1.4A UPS output
  • Power Connections: 8-pole plug connector, Power Status output and PC_ON input for shutdown connections
  • Delivery: Worldwide via global network
