C6915-0010

Original price $6,778.00 - Original price $6,778.00
Original price
$6,778.00
$6,778.00 - $6,778.00
Current price $6,778.00
Available, Shipping Varies
The Beckhoff C6915-0010 is a compact industrial PC designed for installation in control cabinets. With dimensions of 48 x 164 x 119mm, a weight of 1.25kg, and a fanless design, the C6915-0010 has internal cooling fins to assist with passive cooling. Before turning off the unit, all software should be properly closed. If not used for control tasks, disconnect from the equipment after all parts are powered down. The PC runs on a Microsoft Windows Embedded Compact 7 OS, powered by an Intel Atom E3815 CPU and 3.5-inch motherboard. For maintenance or upgrades, power supply must be turned off. The C6915-0010 features easily removable front flap for access to flash storage and battery, dual RJ-45 connectors for LAN connectivity, and an X101 socket for power, with the earthing connection on the mounting plate. To avoid condensation, the unit should adjust to room temperature for about 12 hours before operation.
30 Day Warranty
Technical Specifications
  • Manufacturer: Beckhoff
  • Product Type: Industrial PC
  • Installation Method: Control cabinets
  • Cooling Method: Passive (internal cooling fins)
  • Dimensions: 48 x 164 x 119 mm (W x H x D) without mounting plate
  • Weight: 1.25kg
  • CPU: Intel Atom E3815
  • Motherboard Size: 3.5-inch
  • Operating System: Microsoft Windows Embedded Compact 7
  • Power Supply Voltage: 24VDC
  • Storage Access: Removable front flap
  • Connectivity: Two RJ-45 connectors
  • Network Compatibility: 10/100/1000 BASE-T Local Area Network
  • Power Supply Connection: X101 socket
  • Earthing Connection: Located on the mounting plate
  • Climate Adjustment: 12 hours
