C9900-U320

Name: C9900-U320
Brand: Beckhoff
Price: 988.57 USD
Availability: InStock

by Beckhoff

$877.97 - $988.57

$988.57

$877.97 - $988.57

$988.57

In Stock, Ships 1 - 3 Days

The Beckhoff C9900-U320 from the C9 PC Accessories series is a robust DIN rail-mountable UPS providing backup power to IPCs with a NiCad battery capacity of 2.5 Ah and an output voltage of 24 VDC. It supports a charging current of 200-800 mA for flexible charging and achieves a full charge in up to 4 hours. Designed for industrial automation, it operates across an ambient temperature range of 0 to 55 °C and tolerates up to 95% non-condensing humidity. Reverse battery protection is ensured by a fuse on the C2000BAT board, safeguarding against incorrect connections. Integration is seamless via ST501 and ST703 ribbon cables controlled by C1230S or CP9030 boards, and Beckhoff recommends cable lengths of 4 m (1.5 mm²) or 8 m (2.5 mm²) for optimal performance.

Contact Us

Email: sales@servosupplier.com

Phone Number: 1-888-551-3082

International: 1-919-443-0207

Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Ambient Temperature For Usage

0 to 40 °C for C9900-U300; 0 to 55 °C for C9900-U320

Battery Capacity

2.5 Ah

Battery Type

NiCad

Charging Current

200-800 mA

Charging Time

Up to 4 hours

Connection Interface

ST501 and ST703 ribbon cables

Max Cable Length (1.5 Mm²)

4 meters

Max Cable Length (2.5 Mm²)

8 meters

Max Humidity

95% non-condensing

Mounting Type

DIN rail

Operating Temperature Range

0 to 55 °C

Output Voltage

24 VDC

Power Supply Voltage

18 V

Reverse Battery Protection

Fuse on C2000BAT board

Ups Control

Controlled by C1230S or CP9030 boards
