CB1061-0001
by Beckhoff
The Beckhoff CB1061-0001 motherboard is part of the CB Modular Motherboards series by Beckhoff. Key features include support for up to 32 GB of DDR3L-1600 RAM across two SO-DIMM204 sockets and dual Gigabit Ethernet ports. Designed around the Intel® Q87 PCH chipset with an LGA1150 socket, it accommodates Intel® 4th Generation Core™ and Celeron® processors. This industrial ATX platform serves the primary function of delivering reliable control, computation and high-speed connectivity in automated manufacturing and control systems.
Measuring 305 mm × 220 mm in standard ATX form factor, this board is equipped with an AMI® Aptio BIOS for secure boot and system management. Expansion capabilities include three PCI sockets, two PCIe-x1 and one PCIe-x4 slot, plus a PCIe-x16 slot for graphics or specialized I/O cards. Storage is handled through six SATA II interfaces supporting up to 6 Gbps data transfer. Peripheral and user-interface connectivity features ten USB 2.0 and four USB 3.0 ports, as well as DVI, HDMI, DisplayPort and VGA video outputs. An integrated High-Definition Audio codec with SPDIF output and multiple GPIO pins allow seamless integration of sensors and actuators.
Power is supplied via a standard ATX connector with an auxiliary 2×2-pin 12 V feed, ensuring stable operation under varying load conditions. The LAN ports conform to 10/100/1000 Base-T standards for network interoperability, and the board’s DDR3L-1600 memory and Intel® CPU compatibility deliver high efficiency in multitasking and real-time data processing. Its industrial-grade design emphasizes durability, vibration resistance and long-term reliability in harsh factory environments. By combining versatile expansion, extensive I/O, robust power delivery and proven chipset performance, the CB1061-0001 enables optimized throughput and dependable operation in complex industrial automation and control applications.
