CB4053

The CB4053 from Beckhoff represents a robust entry in the CB Modular Motherboards lineup, integrating an Intel Atom 1.6 GHz processor within a compact PC/104+ form factor. Designed specifically for industrial automation, this board delivers reliable compute performance while maintaining a small footprint for space-constrained environments. Key specifications include a Phoenix BIOS for stable firmware management, a SATA storage interface for high-speed data access, and integrated CH7317A graphics to support local display output without external GPU modules. The unit’s efficient US15W power supply consumption further underscores its suitability for embedded and long-term applications, striking a balance between performance and energy use. With its stackable architecture and lightweight design, the CB4053 simplifies system integration in rugged industrial settings.

Technical capabilities of the CB4053 extend beyond its processor core. The board features a single SODIMM DDR2-533 memory slot supporting up to 1 GB of PC2 5300S RAM, ensuring smooth execution of control tasks and real-time monitoring. Network connectivity is provided by an 82573L network controller, delivering reliable Ethernet communication, while legacy interfaces such as JAE 50 pin IDE connectors remain available for backward compatibility with specialized peripherals. The integrated ALC885 audio codec handles audio I/O functions, supporting diagnostic alerts or operator feedback. The onboard 82801DB motherboard chipset orchestrates data traffic between subsystems with minimal latency, further enhancing overall system responsiveness.

Operational features emphasize durability and flexibility in industrial deployments. The CB4053’s Mini PCIe expansion slots enable custom add-on modules such as fieldbus adapters, wireless communications or solid-state storage upgrades without altering the core board. A comprehensive array of USB, Ethernet, and VGA interfaces allows seamless connection to sensors, HMIs, and supervisory control systems. The combination of SATA storage and low-power US15W operation reduces heat generation, minimizing cooling requirements and extending component lifespan. Its PC/104+ stackable design ensures secure mechanical coupling and simplifies wiring within control cabinets or mobile platforms.

Integration is straightforward thanks to the CB4053’s adherence to established industrial standards. The board easily slots into existing PC/104+ backplanes or custom enclosures, simplifying installation and maintenance. Its balanced mix of modern interfaces and legacy connectivity makes it ideal for applications ranging from machine vision and robotics to process control and data logging. With Beckhoff’s proven track record in industrial computing, the CB4053 offers a dependable foundation for developing automated systems that demand uninterrupted operation and precise performance.
