manufacturer image of CCD01.1-KE00-01

CCD01.1-KE00-01

by Bosch Rexroth Indramat
$3,121.23 - $3,121.23
$3,121.23
$3,121.23 - $3,121.23
$3,121.23
In Stock, Ships 1 - 2 Days
The Bosch Rexroth Indramat CCD01.1-KE00-01 is a terminal box crafted for the accommodation of option cards. Belonging to Bosch's CCD series, this model is equipped with a four-slot rack assembly and a 24V COMM input. It incorporates a SERCOS III interface adhering to IEEE 802.3 standards for efficient communication. The terminal box connects via two eight-pin RJ 45 type connectors to the control section. Ethernet compatibility, both in 10 Base-T and 100 Base-T standards, is ensured through compliance with IEEE 802.3i and 802.3u specifications respectively. Featuring four LEDs -- two yellow to indicate data transmission, and two green to signify link connection -- the product is 10.5 x 19 x 21 cm and lightweight at 2.8kg. The H1 LED designates power status.
30 Day Warranty
Technical Specifications
  • Product Name: CCD01.1-KE00-01
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Box Terminal
  • Series: CCD
  • Slots: 4
  • Rack Assembly: Yes
  • COMM Input: 24V
  • Interface: SERCOS III (IEE 802.3 Standards)
  • Connectors: Two RJ 45 (8 pins: 2 differential outputs, 2 differential inputs)
  • Cable Specification: CAT 5
  • Differential Inputs Connection: Pin 3 and Pin 6
  • Differential Outputs Connection: Pin 1 and Pin 2
  • Ethernet Standards Compatibility: 10 Base-T and 100 Base-T (IEEE 802.3i and IEEE 802.3u)
  • LED Indicators: Four (Two yellow- H10, H12 and Two green-H11, H13)
  • Size: 10.5 x 19 x 21 cm (L x W x H)
  • Weight: 2.8kg
  • Power Status Indicator: H1 LED
