S image of CCD01.1-KE11-01-FW

CCD01.1-KE11-01-FW

by Bosch Rexroth Indramat
$4,371.50 - $4,371.50
$4,371.50
$4,371.50 - $4,371.50
$4,371.50

In Stock, Ships Fast

The Bosch Rexroth Indramat's CCD01.1-KE11-01-FW is a high-quality box terminal from their CCD product line. Featuring four plug-in slots for option cards, this unit integrates seamlessly with other motion controllers from the same manufacturer. The operative status of the terminal can be easily viewed via the H1 LED indicator. It utilizes custom firmware from the manufacturer and promotes cross-communication through a SERCOS III interface. The two RJ 45 connectors each have a yellow and green LED indicator and four functional pin slots. Pins one and two serve as differential outputs A and B while pins three and six take on differential inputs A and B, transmitting and receiving 10/100 Base-T signals respectively. The firmware required for operation is a separate add-on purchase. The unit is lightweight and portable, weighing only 2.4kg and featuring dimensions of 21x11x19 cm (LxWxH).

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Model

CCD01.1-KE11-01-FW

Product Line

CCD

Card Slots

4

Use Case

Used with motion controllers from the same manufacturer

LED Status Indicator

H1 LED

Cross-Communication

Supports via SERCOS III interface

Connector Type

2 RJ 45 type connectors, each with a yellow and green LED and 8 pins

Pin Functions

First two pins - differential outputs A and B; Third and Sixth pins - differential inputs A and B

Signal Compatibility

10 Base-T signals and 100 Base-T signals as per IEEE 802.3i and IEEE 802.3u standards respectively

Firmware

Separately ordered as a sub-item

Housing

Offers a shield connection

Network Connection Indication

Green LEDs

Data Transmission Indication

Yellow LEDs

Dimensions

21 x 11 x 19 cm (L x W x H)

Weight

2.4kg
