series image of CDB01.1C-SE-ENS-ENS-EN1-EN1-NN-S-NN-FW

CDB01.1C-SE-ENS-ENS-EN1-EN1-NN-S-NN-FW

by Bosch Rexroth Indramat
Request a quote
The Bosch Rexroth Indramat CDB01.1C-SE-ENS-ENS-EN1-EN1-NN-S-NN-FW control section is a robust unit lacking a safety option and exhibiting a non-linear input resistance for its probe inputs. The unit supports up to 20 mounting or dismounting actions and leverages high-side switches for digital outputs, which can actively sink the supply current. The unit uses free-wheeling diodes to curb voltage peaks at the relay coils, includes a distortion LED in its SERCOS interface, and a RS 232 serial interface at the X2 connecting point. The device requires connections via wire ends with ferrules, using specified crimping tools. The unit's electrical specifications include an inrush current of 6A and power needs supplied via 0V and 24V terminal connectors. The product's features include reduced voltage peaks when inductive loads are switched off, bounce-free electronic switches for probe inputs, and a SERCOS interface for programming and diagnosis during servicing. The unit has a power consumption of 9W at 24VDC.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Code: CDB01.1C-SE-ENS-ENS-EN1-EN1-NN-S-NN-FW
  • Safety Option: None
  • Input Resistance: Non-linear, varies with input voltage
  • Mounting/Dismounting Limit: 20 times
  • Digital Output Mechanism: High-side switches
  • Voltage Peak Limitation: By direct use of free-wheeling diodes at relay coil
  • SERCOS Interface Feature: Distortion LED
  • Serial Interface Type: RS 232 at X2 connecting point
  • Connection Method: Wire ends with ferrules, using crimping tools
  • Inrush Current: 6A
  • Power Supply: Through 0V and 24V terminal connectors at power section
  • Analog Input Connection Type: Cable with shield at either end
  • Power Consumption: 9W at 24VDC including multimedia card and control panel
  • Digital Output Feature: Energy absorption capacity to limit voltage peaks with inductive loads
  • Probe Input Control: With bounce-free switching elements, eg. electronic switches
  • Switching Frequencies: Three
  • Control Cycle Times: Two current control, velocity control, position control
  • SERCOS Interface Use: Programming, diagnosis, parameterization during servicing and commissioning
  • Transport Assistance: Dedicated logistics team with worldwide network.
