C image of CE06250 | Main (Front Left)

CE06250

by Kollmorgen
$3,411.02 - $3,411.02
$3,411.02
$3,411.02 - $3,411.02
$3,411.02

In Stock, Ships 1 - 3 Days

The Kollmorgen CE06250 is a high-quality Servostar Series 2 servo motor amplifier, proficient with both single-phase and three-phase, for 115 Volts AC or 230 Volts AC inputs. It features varying power levels and continuous currents based on the type of input voltage used. In terms of output, it has a rated current of 6 Amps, peaking at 18 Amps for a 500 millisecond duration or at 12 Amps for a 2-second duration. Additionally, it offers sine encoder feedback, protective functionality against operational mishaps like overvoltage, undervoltage, and overtemperature happenings. Be mindful of operation conditions as the amplifier's output is subject to derating if used outside recommended parameters. It dissipates 80 watts of heat and should be operated in an ambient temperature within 41 to 113 degrees Fahrenheit and at an altitude below 1000 meters.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Model

CE06250

Series

Servostar Series 2

Type

Servo Motor Amplifier

Input (115V AC, single-phase)

0.89 kVA, 10 A continuous, 30 A peak

Input (115V AC, three-phase)

1.1 kVA, 7.8 A continuous, 15.6 A peak

Input (230V AC, single-phase)

1.8 kVA, 10 A continuous, 30 A peak

Input (230V AC, three-phase)

2.8 kVA, 7.8 A continuous, 15.6 A peak

Rated Output

6 A

Peak Output Current

18 A for 500ms, 12 A for 2s

Output (115V AC, 45C, single-phase)

0.7 kVA

Output (115V AC, 45C, three-phase)

1.1 kVA

Output (230V AC, 45C, single-phase)

1.4 kVA

Output (230V AC, 45C, three-phase)

2.2 kVA

Feedback type

Sine Encoder

Logic Input

230 Volts

Protection

Undervoltage Trip, Overvoltage Trip, Overtemperature Trip

Power Dissipation

80 W

Operating Temperature

41-113 degrees Fahrenheit

Maximum Operating Altitude

1000 meters

Derating

Occurs outside recommended ambient conditions.
