P image of CFL01.1-E2

CFL01.1-E2

by Bosch Rexroth Indramat
$449.58 - $3,195.00
$449.58
$449.58 - $3,195.00
$449.58
The CFL01.1-E2, a functional module by Rexroth, comes with speedy input/output capabilities. It features 8 pre-configured inputs, 8 freely configurable outputs, and an additional 8 channels that can function as either input or output. Inputs typically delay at 45 μs and outputs at 70 μs. Designed for expanding any CML control, the unit comes with IP20 protection, making it touch-safe and dust-resistant. It operates effortlessly within the ambient temperature of +5 to +55°C and 5-95% relative humidity. Both inputs and outputs use 1-wire connectivity. The sensor supply and output voltage are 24 V DC, with input voltage varying from <5 low level to >11 high level. The unit's rated output current is 500 mA and the lamp load is 5 W. It possesses a protection size of SG1 (6.2W), consumes 0.3W of power, is UL 508 certified, and adheres to the NFPA 70 National Electrical Code.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Rexroth

Product Model

CFL01.1-E2

Feature

Fast input and output

Preconfigured Inputs

8

Freely Configurable Outputs

8

Additional Channels

8 (configurable as inputs or outputs)

Typical Input Delay

45 μs

Typical Output Delay

70 μs

Protection Type

IP20

Ambient Temperature Range

+5 to +55°C

Relative Humidity Range

5% to 95%

Input Connectivity

1 wire technology

Input Voltage Range

< 5 low level to >11 high levels

Sensor Supply

V DC 24

Output Connectivity

1 wire technology

Output Voltage

24 V DC

Rated Output Current

500 mA

Lamp Load

5 W

Output Protection Size

SG1 (6.2 W)

Power Consumption

0.3 W

Certification

UL 508, NFPA 70 National Electrical Code.
