CMP40.2-SP-304-FN-NNNN-NW

Original price $0.00 - Original price $0.00
Original price
Request a Quote
$0.00 - $0.00
Current price Request a Quote

Request a quote

Add a Message
The CMP40.2-SP-304-FN-NNNN-NW is a CNC Control Module, main unit of the Rexroth IndraMotion MTX standard control, developed by Bosch Rexroth Indramat. It incorporates CNC/PLC functionalities and is tailored for unassigned PCI slots of PCs. With dual voltage adaptability for both 5 and 3.3 volts, it also features an optional eight-node high-speed I/O interface. The module boasts maximum eight axes, a four ms Ipo cycle duration, four interpolated channels and just 15 microseconds of PLC processing period. Within it is an Intel Celeron 650 MHz processor, 8MB SRAM and 64MB SDRAM. An external battery aids its data backup. The control module operates efficiently at an atmospheric pressure up to 2700 meters above sea level, with a temperature range between 5 to 55 oC and a relative humidity of 5 to 95%. Its power consumption is 21 W with a maximum current of 5A, supplied at 5V DC.

Contact Us

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer


Bosch Rexroth Indramat

Product Type


IndraControl P40 CNC control module

Installation


For unallocated PCI slots of PCs

Interface


Universal PCI bus interface

Voltage Compatibility


5 Volts and 3.3 Volts

Design


PCI slot module

Maximum Axes


8

Ipo Cycle Time


4 ms

Interpolated Channels


4

PLC Processing Time


15 microseconds

Processor


Intel Celeron 650 MHz

SRAM


8 MB

SDRAM


64 MB

Data Backup


Externally mounted battery

Fan


Onboard fan

Operating Atmospheric Pressure


Up to 2700 meters above sea level

Storage Atmospheric Pressure


Up to 3000 meters above sea level

Storage Temperature


-20 oC – 70 oC

Operating Temperature


5 – 55 oC

Shock Resistance


15 g in all axes

Relative Humidity


5 – 95 %

Power Consumption


21 W

Maximum Current


5 Amperes

Voltage Supply


5V DC
