CP7809-0001-0000
by Beckhoff
The Beckhoff CP7809-0001-0000 is a rugged industrial control panel in the CP Panel PC Systems series, designed and manufactured by Beckhoff for durable human–machine interfaces. Featuring a 6.5-inch display with a native resolution of 640 x 480 pixels and a robust IP 65 protection rating, this Panel PC is optimized for harsh environments. The system’s primary application is to provide reliable operator control and monitoring of automated machinery, combining a high-visibility touchscreen interface with integrated DVI and USB connectivity for seamless data exchange.
Incorporating three IP 65 round connectors dedicated to DVI video output, USB communication, and 24 V power supply, the CP7809-0001-0000 ensures secure signal transmission in industrial settings. The housing is constructed from anodized aluminum, offering both electromagnetic shielding and mechanical resilience. The rear panel features 4 M6 x 18 mm threaded holes for versatile mounting with adapter plates or mounting arms. An optional touch screen pen with holder enhances precision input, while a choice of five front laminate variants—including function keys, numeric keyboard, and 10 PLC special keys with LED—allows customization for specific control tasks.
With an operating temperature range of 0...55 °C, this Panel PC maintains performance in temperature-variable environments. The maintenance-free front panel requires only a soft, damp cloth for cleaning, preserving its scratch-resistant surface. The integrated DVI/USB interfaces and 2-port IP 65 USB connector option enable compatibility with a wide range of peripheral devices and automation components. Certified to IP 65 standards, the aluminum-housed CP7809-0001-0000 delivers reliable performance, minimal downtime, and simplified system integration, making it an ideal choice for industrial applications that demand durability, precision, and operational efficiency.
