S image of CS351S-G

CS351S-G

by Bosch Rexroth Indramat
$16,726.49 - $18,399.14
$18,399.14
$16,726.49 - $18,399.14
$18,399.14

Available, Shipping Varies

The CS351S-G model, manufactured by Bosch Rexroth Indramat, is a compact system that integrates with ErgoSpin or CC-ErgoSpin handheld nut runners or tightening spindles. Operating on a 1-phase AC 110 – 230 V power source with 50/60 Hz frequency, it provides a continuous current of 10 A (at 120 V)/ 5.2 A (at 230 V) and delivers 1200 VA of nominal power. The model weighs 9.9 kg and is best installed vertically. It operates optimally in temperatures of 0-45 degrees Celsius and relative humidity of 20-90% (non-condensing). The CS351S-G utilizes 26 W/ 23 W of power (with screensaver active) and is equipped with IP 54 protection to prevent dust ingress and water splashing. It features a TFT display with built-in touch screen, IEC 61131-3 compliant logic, a servo amplifier, and power supply unit among other specifications.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Model

CS351S-G

Intended Use

Use with ErgoSpin or CC-ErgoSpin handheld nut runners or tightening spindles

Power Source

1-phase AC 110 – 230 V (±10% tolerance, 50/60 Hz)

Continuous Current

10 A (at 120 V)/ 5.2 A (at 230 V)

Nominal Power

1200 VA

Net Weight

9.9 kg

Mounting Direction

Vertical

Power Consumption

26 W/ 23 W (with activated screensaver)

Operating Temperature

0 – 45 degree Celsius

Relative Humidity

20% to 90% (without condensation)

Protection Class

IP 54

Features

Servo amplifier, power supply, TFT display (VGA 640×480) with integrated touch screen, logic complaint with IEC 61131-3, integrated computer unit, controller and slots for optional interface cards

Connectivity

Micro-S memory card slot, status bar (St1, St2), reset button, RS232 interface, 1 DVI interface, 3 USB interfaces, 1 Ethernet interface

Battery

Built-in 3 V lithium cell for storing tightening results.
