series image of CSH01.1C-NN-EN1-MA1-MD2-S1-S-NN-FW

CSH01.1C-NN-EN1-MA1-MD2-S1-S-NN-FW

by Bosch Rexroth Indramat
Request a quote
The CSH01.1C-NN-EN1-MA1-MD2-S1-S-NN-FW is a premium control section designed and produced by Bosch Rexroth Indramat. Configurable in nature and designed for single-axis usage, this unit finds its placement within the manufacturer's drive controller's power section. As part of the CSH series, this component measures 241 x 103 x 49.5 mm and boasts integrated safety technology within its single configuration slot. Despite its independent type plate, it is critical that only authorized individuals handle its mounting and dismounting. Vulnerable to electrostatic charges, correct usage is paramount for user safety and product integrity. With no capacity for master communication, the unit features one Normally Open relay contact, two controller cycle times, and various digital inputs and outputs. An optional HSF / RSF encoder and memory card compatibility highlight its versatility, while a protective diode offers safeguards against incorrect power supply connections.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Code: CSH01.1C-NN-EN1-MA1-MD2-S1-S-NN-FW
  • Mounted Inside: Manufacturers Drive Controller
  • Configurable: Yes
  • Number of Axes: 1
  • Product Group: CSH
  • Configuration Slot: 1 with safety technology
  • Size: 241 x 103 x 49.5 mm
  • Risk Factor: Damage due to electrostatic charges
  • Usage: Industrial environments
  • Modifications: Not allowed
  • Relay Contact: 1 Normally Open
  • Line Code: 1
  • Master Communication Support: No
  • Control Cycle Times: Two velocity, position and current
  • Digital Inputs and Outputs: Multiple
  • Design Code: 1
  • Encoder: HSF / RSF encoder on X4.1 female D-Sub connectors with 15 poles
  • Typical Voltage Supply: 11.6 volts
  • Maximum Output Current: 500mA
  • Sine Output Frequency: 4kHz
  • Memory Card Insertion: Allowed through X7 connector
  • Power Supply Protection: Yes, by a protective diode.
