S image of CSH01.1C-NN-EN1-NNN-MA1-NN-S-NN-FW

CSH01.1C-NN-EN1-NNN-MA1-NN-S-NN-FW

by Bosch Rexroth Indramat
$4,161.33 - $4,161.33
$4,161.33
$4,161.33 - $4,161.33
$4,161.33

In Stock, Ships 1 - 3 Days

The Bosch Rexroth CSH01.1C-NN-EN1-NNN-MA1-NN-S-NN-FW is an advanced control section designed to be integrated inside the drive controller's power section. It features sensor and actuator requirements for effective monitoring, and an HSF / RSF encoder, fitted to the X4 connector, which rates a maximum output current of 70mA and a minimal DC load resistance of 35 Ohms for resolver feedback. It has no optional module on the X8 connector but includes an analog I/O extension module on the X10 connector. This module, which consumes 2W power, provides two analog outputs and two differential analog inputs. The advanced section accommodates a pulse width of up to 100ms and supports wiring in its spring terminals. The product employs digital outputs realized via high-side switches, and is protected against overloads and short circuits. With a standard control panel, the user can set drive address, analog inputs and establish position data reference. Distribution is managed through a reliable vendor network.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Code

CSH01.1C-NN-EN1-NNN-MA1-NN-S-NN-FW

Product Type

Advanced Control Section

Placement

Inside the Drive Controller

Required Extra Parts

Additional Sensors and Actuators for Monitoring and Controlling

Encoder Specifications

Maximum Output Current Rating of 70mA and Minimum DC Load Resistance of 35 Ohms (for Resolver Feedback)

X8 Connector

Does Not Comprise Any Optional Module

X10 Connector

Fitted with an Analog I/O Extension Module (with Two Analog Outputs and Two Differential Analog Inputs)

Power Consumption (X10)

2W

Maximum Pulse Width

100ms

Wiring Support

Wire Ends With or Without Ferrules (Preference for Without Ferrules)

Digital Output Type

High-Side Switches (Non-Sinkable, overload and short circuit protected)

Relay Contact Specifications

Maximum Contact Resistance of 1,000 milliohms at Minimum Current

Control Panel Features

Ability to Set Drive Address, Analog Inputs, and Establish Position Data Reference

Delivery

Through a Trustworthy Vendor Network.
