series image of CSH01.1C-NN-ENS-EN2-EN2-NN-S-NN-FW

CSH01.1C-NN-ENS-EN2-EN2-NN-S-NN-FW

by Bosch Rexroth Indramat
Request a quote
The CSH01.1C-NN-ENS-EN2-EN2-NN-S-NN-FW is an integral component of the advanced Rexroth IndraDrive system, expertly engineered by Bosch Rexroth Indramat. This single-axis control section, belonging to the CSH01 series, is renowned for excellence in drive and motion control. It fits precisely into the IndraDrive setup, NEoperating seamlessly alongside motors, gearboxes, control units, and power units. The device is equipped with a standard encoder evaluation interface, enabling the connection of 12V supply voltage encoders such as the MSK motors of the IndraDyn S family and the sin-cos encoders with Hiperface and EnDat 2.1 interfaces. It also accepts 5V encoders. Utilizing the IndraWorks software, this control section supports remote commissioning, programming, and diagnostics. It's primarily designed for industrial use (Category C3, IEC 61800-3) and requires radio interference filters when used in residential areas. Its control panel optimizes drive address setting, load default procedures, position data references, and analog output settings.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Line: CSH01 Series
  • Product Type: Control Section
  • Control Range: ADVANCED control section range
  • Configuration: Configurable Single-Axis Control Section
  • Encoder Interface: Standard Encoder Evaluation Interface
  • Supply Voltage: 12V for some Encoder Systems, 5V for other Encoder Systems
  • Encoders Compatibility: Encoders of MSK motors of IndraDyn S family, Sin-Cos Encoder (1 Vpp) with Reference Track, Sin-Cos Encoders (1 Vpp) with Hiperface and EnDat 2.1 interfaces
  • Commissioning: Via Rexroth IndraWorks software
  • Routines: Setting Drive Address, Basic Load Defaults Procedure, Position Data Reference, Analog Outputs
  • Usage Area: Industrial, Category C3 according to IEC 61800-3
  • Mains Supply: Public Mains Supplying Residential Areas with Radio Interference Filters if necessary
