series image of CSH01.1C-NN-ENS-NNN-MD2-NN-S-NN-FW

CSH01.1C-NN-ENS-NNN-MD2-NN-S-NN-FW

by Bosch Rexroth Indramat
Request a quote
The Bosch Rexroth Indramat CSH01.1C-NN-ENS-NNN-MD2-NN-S-NN-FW is a control section that forms part of a drive controller, overseeing the operation of the attached electrical motor. It features terminal connectors at 0V and 24V, isolated inputs/outputs at X31 and X32 connection points, and a pulse width maximum of 110ms. Special care must be taken when handling the device to avoid damage, requiring grounding before contact with people, tools, or parts. As it is not waterproof, installation must follow the directions provided in the documentation. Usage in public low voltage mains may result in high frequency interference. This device should only be operated by qualified personnel, with connector usage restrained to when the device is unpowered. Comprising a drive controller type plate and separate type plate, the unit has a single-axis set-up, one analog voltage input, and an MD2 optional module with digital I/O extension and SSI encoder interface at the X10 connection point.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Code: CSH01.1C-NN-ENS-NNN-MD2-NN-S-NN-FW
  • Terminal Connectors Voltage: 0V and 24V
  • Maximum Pulse Width: 110ms
  • Input/Output Connect Points: X31 and X32
  • Connection Points Features: Screw terminal blocks and spring terminals
  • Contact Procedure: Contact only after prior discharge through a grounding action
  • Packaging: Conductive packaging
  • Function: Control and monitor the operation of the connected electrical motor
  • Installation: As per instructions in the documentation
  • Operation Limitation: Does not support operation under water; Avoid utilization in public low voltage mains
  • Operation Requirement: Qualified and trained personnel; Connect with an equipment grounding conductor permanently
  • Connection Rules: No plugging or removal of connectors when powered
  • Warning: Potential dangerous movement due to wrong cable connection or wiring
  • Type Plate: Separate type plate featuring its type designation
  • Configuration: Single-axis
  • Analog Voltage Input: One
  • Optional Module: MD2 featuring a digital I/O extension with an SSI encoder interface at the X10 connect point.
