S image of CSH01.1C-PB-EN2-EN2-MA1-NN-S-NN-FW

CSH01.1C-PB-EN2-EN2-MA1-NN-S-NN-FW

by Bosch Rexroth Indramat
$2,217.81 - $2,217.81
$2,217.81
$2,217.81 - $2,217.81
$2,217.81

In Stock, Ships 1 - 3 Days

The Bosch Rexroth Indramat’s product, CSH01.1C-PB-EN2-EN2-MA1-NN-S-NN-FW, is a configurable control section for IndraDrive controllers with optimal operational temperatures of 0 to 40 degrees Celsius and up to 1000 meters elevation. Its structure comprises a basic unit and optional module slots. The unit, which vertically mounts, consumes 7.5 watts of power, 24 volts from the power section. It also incorporates two encoder EnDat 2.1 modules, each consuming 6 watts, and an analog I/O extension module using 2 watts, while the optional control panel absorbs 1 watt, totally using 22.5 watts. This device comes with integrated RS-232 serial communication, Profibus master communication, a slot for a removable memory card, and has three type plates. With dimensions of 241 x 103 x 49.5 millimeters, the unit cools via convection naturally, being suitable for single-axis applications. It allows configurable control cycle times and supports different switching frequencies.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Name

CSH01.1C-PB-EN2-EN2-MA1-NN-S-NN-FW

Product Type

configurable control section for Bosch IndraDrive controllers

Power Source

Power section mount

Output Voltage

24 Volts

Power Consumption(Basic Unit)

7.5 Watts

Power Consumption(Encoder EnDat 2.1 module)

6 Watts each

Power Consumption(Analog I/O extension module)

2 Watts

Power Consumption(Control Panel)

1 Watt

Total Power Consumption

Approximately 22.5 Watts

Dimensions

241 x 103 x 49.5 millimeters

Mounting Type

Vertical

Cooling Method

Natural convection

Operating Temperature

0 to 40 degrees Celsius

Optimal Elevation

Up to 1000 meters

Number of Type Plates

Three (Power section, Firmware, and Control section)

Applications

Single-axis

Communication

Profibus master and integrated RS-232 serial communication port

Additional Features

Slot for removable memory card, Two integrated analog I/O

Current Control Cycle Time

62.5 / 125 microseconds

Velocity Control Cycle Time

125 / 205 microseconds

Position Control Cycle Time

250 / 500 microseconds

Supported Switching Frequencies

2 / 4 / 8 / 12 / 16 kilohertz
