series image of CSH01.1C-SE-EN2-EN2-MEM-S2-S-NN-FW

CSH01.1C-SE-EN2-EN2-MEM-S2-S-NN-FW

by Bosch Rexroth Indramat
Request a quote
The Bosch Rexroth Indramat product CSH01.1C-SE-EN2-EN2-MEM-S2-S-NN-FW is a key element in the IndraDrive drive system. As an ADVANCED CSH control section model, it is a notable example of Bosch Rexroth's configurable drive controllers. This particular model is built with an encoder emulation interface, specially designed to emulate both absolute value and incremental encoder signals. These signals are electrically isolated from the main circuit and do not require an external power source. The device incorporates a SERCOS interface which enables seamless communication with higher-level control systems, and the fiber optic connection provides high resistance to electromagnetic interference. This model operates at various switching frequencies and includes a panel for executing multiple functions. With two encoder evaluation interfaces, the CSH01.1C-SE-EN2-EN2-MEM-S2-S-NN-FW can accommodate a wide range of encoders with a supply voltage rating of 5V. Its suitability for industrial applications rounds off its features.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Model: CSH01.1C-SE-EN2-EN2-MEM-S2-S-NN-FW
  • Product Type: ADVANCED CSH Control Sections
  • Type: Configurable
  • Encoder Emulation Interface: Yes
  • Power supply: No external required
  • Communication Interface: SERCOS
  • Connection: Fibre Optic Cable
  • Switching Frequencies: 2kHz, 4kHz, 8kHz, 12kHz, 16kHz
  • Maximum Pulse Width: 100ms
  • Inrush Current: 4A
  • Control Panel Functions: Position data reference setting, error memory access, drive address setting, basic load defaults procedure start
  • Display Type: Single-line
  • Operating Keys: Four
  • Encoder Evaluation Interfaces: Two
  • Supply Voltage Rating: 5V
  • Encoders Supported: Sin-cos encoder (1 Vpp) with reference track, 5V-TTL square-wave encoder with reference track, Sin-cos encoder (1 Vpp) with EnDat 2.1 and sense lines.
  • Operating Environment: Industrial areas
  • Compliance: Category C3 per IEC 61800‑3
