CSH01.3C-PB-ENS-MA1-CCD-S2-S-NN-FW

Request a quote
The Bosch Rexroth Indramat CSH01.3C-PB-ENS-MA1-CCD-S2-S-NN-FW is an advanced single-axis control section extensively used in machine tools and paper processing machines. Known for its top-notch functionality, it belongs to IndraDrive drive controllers, divided into a control section and power section. Along with multiple interfaces, the control section is equipped with a standard control panel. With it, users can perform various actions including setting the drive address and analog outputs, triggering the basic load defaults procedure, and generating position data references. The control panel also features a single-line display showing operating states, prompt warnings, command and error diagnostics. It also has four operational keys to function smoothly. Reliability is further ensured via its connection points having spring terminals and screw terminal blocks. The control section is compatible with encoders like the Resolver, the Hall sensor box SHL01.1, and Rexroth's Digital servo feedback. There's also an option for adding more analog channels through the Analog I/O Extension.
30 Day Warranty
Technical Specifications
  • Brand: Bosch Rexroth Indramat
  • Product Type: CSH Control Section
  • Product Range: ADVANCED
  • Control Panel: Standard
  • Display: Single Line Display
  • Function Keys: Four
  • Terminal Connections: Spring terminals and screw terminal blocks
  • Compatible Encoders: Resolver without data memory, Hall sensor box SHL01.1, and Digital servo feedback by Rexroth
  • Encoder Connection: Resolver and HSF encoder evaluation interface with DC 8v or AC 18.2V peak-peak
  • Analog I/O Extension: 2 differential analog input channels (±10V), 2 analog output channels (±10V)
  • Analog Signal Resolution: 12-bit.
