P image of CSH02.1B-ET-EC-NN-S4-NN-NN-FW

CSH02.1B-ET-EC-NN-S4-NN-NN-FW

by Bosch Rexroth Indramat
$15,630.61 - $15,630.61
$15,630.61
$15,630.61 - $15,630.61
$15,630.61

In Stock, Ships Fast

The Bosch Rexroth Indramat CSH02.1B-ET-EC-NN-S4-NN-NN-FW advanced control section is used for wiring spring terminals, supporting both types of wire ends with and without ferrules. A stripped length of 10mm is required for wire ends assembling. The device operates below a 5A maximum inrush current rating, its Type 2 relay can load maximum 30V voltage and allows up to 350mA output current for each digital output of its safety technology module. It features shielded cables for its connections when the cable length exceeds 30m. Safe operation is ensured by limiters that restrict the operation during elevated temperatures. The provided control panel displays command and error diagnoses along with memory support through flash and FRAM. Particularly critical is to avoid removing the optional modules when the power supply is active. The device can be delivered worldwide.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Type

CSH02.1B-ET-EC-NN-S4-NN-NN-FW Advanced Control Section

Terminal Wiring Support

Wire ends with and without ferrules

Stripped Wire Length

10mm

Shield Requirement

Required for analog outputs and inputs

Maximum Inrush Current Rating

Less than 5A

Relay Type

Type 2

Maximum Voltage Load of Relay

30V

Power Consumption

Variable, based on optional modules

Cable Requirement For Analogue Input

Shielded cables for lengths more than 30m

Output Current For Each Digital Output

Up to 350 mA

Operating Temperature

Must not be very high

Digital Output Type

High-side switches, can only actively supply current

Energy Absorption Capacity

Present to limit voltage peaks with inductive loads

Switching Elements

Bounce-free elements like electronic switches

Maximum Pulse Width

1ms

Control Panel Functions

Display command and error diagnoses, function as a programming module

Control Panel Memory

Flash memory for data and code, FRAM memory for data retention

Multipurpose Input Type

Can function as either voltage or current inputs

Global Delivery

Available
