series image of CTP22NLF19NAA00

CTP22NLF19NAA00

by Kollmorgen
$1,200.00 - $1,200.00
$1,200.00
$1,200.00 - $1,200.00
$1,200.00
In Stock, Ships 3 - 5 Days
The CTP22NLF19NAA00 is a high-torque step motor manufactured by Kollmorgen, part of the CT series product category. It features a frame size of 23/5.7 cm, 2 stack-length, NEMA mounting through holes, and a lead-style construction with four connections. This motor also offers a round, smooth shaft modification. As a result of its larger rotor diameter, robust rotor magnets, and computer-controlled windings, it delivers an elevated 25% torque, regardless of speed. This efficient step motor leads to an overall reduction in system cost and energy usage. The motor's design includes aluminum end-caps and a cooling shell for effective heat removal, leading to higher current and torque ratings. It possesses a large bearing system for managing high thrust loads and side loading, overcome the need for coupling and load support bearing. The CTP22NLF19NAA00's innovative high-voltage insulation design heightens reliability and voltage rating. Its use enhances the efficiency of any motion control solution.
30 Day Warranty
Technical Specifications
  • Manufacturer: Kollmorgen
  • Product Series: CT series
  • Type: Step Motor
  • Frame Size: 23/5.7 cm
  • Length: 2 stacks
  • Mounting Style: NEMA mounting through holes
  • Construction Style: Leads
  • Number of Connections: Four
  • Shaft Style: Smooth round optional
  • Torque Production: High, 25% more regardless of speed
  • Energy Efficiency: High, reduces system cost and energy usage
  • Cooling System: Aluminum end-caps and cooling shell
  • Shaft Load Capacity: Radial load of 20lbs and axial load of 50lbs
  • Maximum Speed: 1500rpm
  • Bearings: Large bearing system, accommodates high thrust loads and high side loading
  • Construction Features: High voltage insulation design, eliminates need for failure-prone gaps and joints
  • Benefit: Maximizes efficiency of motion control solutions
