CTP31NLF09KAA00

Original price $0.00 - Original price $0.00
Original price
Request a Quote
$0.00 - $0.00
Current price Request a Quote

Request a quote

Add a Message
Kollmorgen, a leading producer of scalable and innovation-rich motion control products, presents the CTP31NLF09KAA00 step motor. This 2-phase, short stack motor offers 200 steps per revolution and operates optimally at temperatures ranging from -20°C to 40°C. With an insulation voltage rating of 340 VDC, it exhibits a detent torque of 0.21 Nm. The mounted motor torque exhibits 4.9 Nm in a bipolar connection while showcasing 3.9 Nm in a unipolar connection. The step motor also features a thermal resistance of 2.02°C/watts and offers a rotor moment of inertia of 1.31 kg-cm2. Weighing an estimated 1.9 kg, CTP31NLF09KAA00’s performance series in bipolar mode typically offers inductance and resistance at 16 mH and 2.02 Ohms +/-10%, respectively, drawing a current of 2.8 amps DC. Meanwhile, the maximum torque series also shows a typical inductance at 16 mH with resistance at 20°C windings.

Contact Us

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Brand


Kollmorgen

Product Type


Step Motor

Model


CTP31NLF09KAA00

Motor Type


Short Stack

Steps


200 per full revolution

Operating Temperature


-200C to 400C

Insulation Voltage Rating


340 VDC

Detent Torque


0.21 Nm

Mounted Torque


4.9 Nm (bipolar), 3.9 Nm (unipolar)

Thermal Resistance


2.020C/watts

Rotor Moment of Inertia


1.31 kg-cm2

Weight


1.9 kg

Performance Series Inductance


16 mH

Performance Series Resistance


2.02 Ohms +/-10%

Performance Series Current


2.8 amps DC

Max Torque Series Inductance


16 mH

Motor Resistance


200C windings
