S image of CU1521-0010

CU1521-0010

by Beckhoff
$1,827.35 - $1,827.35
$1,827.35
$1,827.35 - $1,827.35
$1,827.35

Available, Shipping Varies

The CU1521-0010 is an EtherCAT media converter from Beckhoff's CU EtherCAT Junctions series that enables conversion between RJ45 copper and single-mode fiber optics. Featuring a Bus Interface with one SC Duplex and one RJ45, it supports a 100 Mbit/s data rate over shielded Cat5 cable to 100 m (100BASE-TX). Powered by 24 V DC (18-30 V) via a 3-pin connection, it delivers low latency (~1 µs) and includes Link Loss Forwarding. With IP20 protection, compliance to EN 61000-6-2/6-4, and an operating range of 0...+55 °C, it is ideal for industrial networks.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Bus Interface

1 SC Duplex, 1 RJ45

Data Medium

shielded Cat5 Ethernet cable

Data Rate

100 Mbit/s

Dimensions (W×H×D)

35×98.5×76.5 mm

Distance

max. 100 m (100BASE-TX)

EMC Immunity/Emission

EN 61000-6-2/-6-4

Feature

Link Loss Forwarding

Humidity

up to 95% RH

Latency

approx. 1 µs

Operating Temperature

0…+55°C

Power Supply

24 V DC (18–30 V), 3‑pin +,–,PE

Protection Rating

IP20

Protocol

EtherCAT

Shock Resistance

EN 60068-2-27

Storage Temperature

–25…+85°C

Vibration Resistance

EN 60068-2-6
