The CU2008-0000 from Beckhoff features 8 Ethernet ports and supports data transfer rates of 10/100 Mbit/s. Part of the CU EtherCAT Junctions, this unmanaged switch mounts on a 35 mm DIN rail and relays incoming frames in half or full duplex.
It draws 100 mA typical current from a 24 V DC supply (18–30 V range) and weighs approximately 320 g. It has an ingress protection of IP20 and operates between 0 and +55 °C.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Approvals
CE, UL
Bus System
Ethernet (IEEE 802.3), store‑and‑forward, unmanaged
Cable Length
up to 100 m (twisted pair)
Current Consumption
100 mA typical
Data Transfer Rate
10/100 Mbit/s, auto‑negotiation, half/full duplex
Dimensions (W×H×D)
85×100×30 mm
Ethernet Interface
RJ45, 10BASE‑T/100BASE‑TX
Ethernet Ports
8
Installation
35 mm DIN rail
Installation Position
variable
LEDs
2 per channel (activity, link, 10/100 Mbit)
Material
V2A stainless steel/aluminum
Operating Temperature
0…+55 °C
Power Supply
24 V DC (18…30 V DC), 3‑pin (+, –, PE)
Protection Rating
IP20
Storage Temperature
–25…+85 °C
Weight
320 g
