The CU2016 from Beckhoff features 16 Ethernet ports and supports 10/100 MBit/s data rates. Part of the CU EtherCAT Junctions, it offers IEEE 802.3u auto-negotiation and RJ45 interfaces. It operates within 0 to +55°C and consumes typically 150 mA.
The unit supports cable lengths up to 100 meters and carries CE and UL approvals. It has an IP20 protection rating. Weighing 400 g, it installs via a 24 V DC 3-pin connection.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Approvals And Markings
CE, UL
Cable Length
up to 100 m twisted pair
Current Consumption
typ. 150 mA
Data Transfer Rates
10/100 MBit/s, IEEE 802.3u auto-negotiation
Dimensions
146 mm x 100 mm x 30 mm
Ethernet Interface
10BASE-T/100BASE-TX Ethernet, RJ45
Hardware Diagnostics
2 LEDs per channel, activity, link, 10/100 Mbit
Installation Position
variable
Material
V2A stainless steel/aluminum
Number Of Ethernet Ports
16
Operating Temperature
0…+55°C
Power Supply
24 (18…30) V DC, 3-pin connection (+, -, PE)
Protection Rating
IP20
Storage Temperature
-25…+85°C
Weight
400 g
