The CX1000-N001 from Beckhoff is a compact module in the CX Embedded PC Systems series, measuring 19 mm x 100 mm x 91 mm and weighing 80 g. It features a 29-pin DVI-I socket and 2 USB 1.1 ports, supports both analog (VGA) and digital (DVI-D) at up to 1024×768, and offers 115 kBaud on two COM interfaces via system bus power.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Applicable Monitor Connection
Supports analog monitors via DVI-to-VGA adapter
Connection Type
DVI-I 29-pin socket + 2 USB ports type A
Data Transmission Compatibility
Both Analog (VGA) and Digital (DVI-D) data supported
Dimensions
19 mm x 100 mm x 91 mm
Interfaces
1 x DVI-I + 2 USB 1.1
Max Baud Rate
115 kBaud on both interfaces (COM1: RXD, TXD, DTR; COM2: RXD, TXD)
Pin Assignment - Dvi-i
Supports TMDS data, DDC Clock/Data, Analog signals
Power Supply
via system bus (through CX1100 power supply module)
Properties
DVI-I interface also carries VGA signals (DVI-A)
Resolution At Monitor
1024x768 (5 m), 800x600 (6 m), 640x480 (7 m)
Usb Interface Compliance
USB 1.1 specification
Weight
Approximately 80 g
