P image of CX5020-0100

CX5020-0100

by Beckhoff
$1,688.72 - $2,339.98
$1,688.72
$1,688.72 - $2,339.98
$1,688.72
The Beckhoff CX5020-0100 is a part of the CX5000 series of embedded PCs, powered by a 1.6GHz Intel Atom® Z530 processor with a single core and hyperthreading technology. It includes an E-bus interface for EtherCAT terminals and 512MB of expandable RAM. There’s a slot for a compact flash card, a 1-second UPS integrated into the flashcard, and various interfaces including two RJ45 ports, four USB 2.0 ports, and a DVI-D port. Unfortunately, it is not compatible with Windows OS or TwinCAT control software. The device is UL Listed and CE Certified, with an IP 20 protection class, and can operate between -25°C and +60°C with up to 95% humidity. LEDs provide diagnostic information. Additionally, it supports PROFIBUS and CANopen master and slave interfaces. Note, this unit should be installed in control cabinets and acclimate to room temperature before operation.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Beckhoff

Product Number

CX5020-0100

Product Type

Embedded PC

Processor

Intel Atom® Z530, 1.6GHz, Single core with Hyperthreading

E-bus interface

Yes, for EtherCAT terminals

RAM

512MB, expandable to 1GB

Storage

Compact flash card slot

UPS

Integrated 1-second UPS persistent memory on flashcard

Connectivity Ports

2 RJ45 ports (10/100/1000 Mbit/s), optional interface, 4 USB 2.0 ports, 1 DVI-D port

Dimensions

100 x 106 x 92mm (W x H x D)

Operating System Compatibility

No Windows OS or TwinCAT control software

Protection Class

IP 20

Dielectric Strength

500V

Battery Compartment

Under front cover, detachable with screwdriver

Certifications

UL Listed, CE Certified

Operating Temperature Range

-25°C to +60°C

Humidity Level

95% without condensation

Diagnostic System

LED setup

Additional Interfaces

Supports PROFIBUS and CANopen master and slave interfaces (9-pin D-sub sockets/plugs)

Installation

In control cabinets.
