P image of CX8051

CX8051

by Beckhoff
$8,624.00 - $8,624.00
$8,624.00
$8,624.00 - $8,624.00
$8,624.00

In Stock, Ships Fast

The Beckhoff CX8051 is a member of the CX80xx Embedded PC product line designed for DIN rail installation within a control cabinet. This device facilitates the transition of analog and digital signals from sensors to actuators via Bus Terminals. Used as slave devices for superior Fieldbus systems or for PLC program processes, the CX8051 requires operation by trained control and automation engineers. Programming and commissioning is done through an Ethernet interface, ensuring data preservation post-system shutdown. It is equipped with numerous components including a 400MHz, 32-bit processor, 512MB MicroSD, 64MB RAM, Ethernet and Fieldbus interfaces, a K/E-bus interface and most notably, a CANopen slave interface with automated baud rate identification. It features a web-based management system, diagnostic LEDs, and has a maximum power loss of 3W. This device functions optimally between 0-55°C, can withstand storage temperatures of -25 to 85°C, and functions at a relative humidity of up to 95%. Lastly, the CX8051 interfaces include a USB device, an Ethernet with an RJ45 connector, and an RS485 CAN interface.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Beckhoff

Product Family

CX80xx

Model

CX8051

Use

DIN rail installation, Control and Automation Engineering

Programming

Via Ethernet Interface

Memory

512MB MicroSD

Interface Types

Ethernet, Fieldbus, K or E-bus

Additional Features

CANopen slave interface, Automatic baud rate detection

Processor

32 bit, 400MHz

RAM

64 MB

Management Feature

Web-based management

Diagnostics LEDs

Power, TC status, and Bus status

Programming Support

TwinCAT PLC

Power Supply

Maximum of 2A

Power Loss

Maximum 3W

Weight

Approximately 180g

Operating Temperature

0 to 55 degrees Celsius

Storage Temperature

-25 to 85 degrees Celsius

Protection Class

IP 20

Humidity

Up to 95% Relative Humidity

Interfaces

USB device, Ethernet RJ45, RS485 CAN
