C image of DDS02.1-W025-DS24-02 | Main (Front Left)

DDS02.1-W025-DS24-02

by Bosch Rexroth Indramat
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The DDS02.1-W025-DS24-02 drive controller, produced by Bosch Rexroth Indramat, is designed for installation in industrial machine control cabinets. It's commonly found in machine tools, textiles, printing and packaging machinery, as well as robotic and handling machines. However, due to the potential danger from voltages exceeding 50 Volts, only trained personnel should install and maintain the device. It's integral for the system's efficiency that the motor feedback data type codes of the motor synchronize with the drive controller. The device operates on a DC bus voltage of 300 Volts and a constant current of 25 Amps. Its energy loss in a control cabinet is capped at 170 W, and it features a digital servo feedback system. The drive controller communicates through a SERCOS interface with firmware version 02 and comes with a variety of accessory kits. With an IP20 rating, it weighs 7.5 kg and can operate in ambient temperatures of 0 to 45 degrees Celsius.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Model

DDS02.1-W025-DS24-02

Product Type

DDS Drive Controller

Typical Applications

Machine tools, Textile, Printing and Packaging Machinery, Robotics and Handling Machines

Voltage

300 Volts

Rated Peak Current

25 Amps

Continuous Current

25 Amps

Current Consumption (Basic Unit at DC +/-15 V)

150 mA

Current Consumption (Basic Unit at DC +24 V)

200 mA

Energy Loss in Control Cabinet

170 W

Motor Feedback System

Digital Servo

Current Consumption (Motor Feedback at DC +/-15 V)

Negligible

Current Consumption (Motor Feedback at DC +24 V)

40 mA

Communication Interface

SERCOS

Firmware Version

02

Accessory Kits

E..-DDS 2, Connector Kit S..-DDS 2, Electrical and Mechanical Kits

Weight

7.5 kilograms

Protection Category

IP20 as per EN60529 / IEC529

Ambient Temperature Range

0 to 45 degrees Celsius
