DDS02.1-W050-DL09-00

by Bosch Rexroth Indramat
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The DDS02.1-W050-DL09-00 is a drive controller produced by Bosch Rexroth Indramat, equipped with a 09 function ID code and a "Bb" ready-to-operate contact. The controller is designed to connect to an adjacent unit through DC bus rails and its control electronics relies on the X1 connector. It supports a connection to a VT-100 terminal or a PC via the RS 232 interface. The product's three-phase connection allows the motor power cable connection, while the signal lines use D subminiature plugin connectors or plugin clamps, needing to be separated from supply lines to avert interference. The device should be mounted on a control cabinet's back wall. It requires a minimum clearance of 80mm at the top and bottom, with cool air entering from the bottom and hot air exiting from the top. The controller complies with DIN 40 050 specifications, protecting against objects with diameters exceeding 50mm. Placement of multiple controllers should consider maximum output and current level.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Code

DDS02.1-W050-DL09-00

Function ID Code

09

Ready-to-operate Contact Type

Bb

Contact Switching Capacity

24VDC/1A

Diagnostic Outputs

2 Analog

Connection Method

DC Bus Rails

Control Electronics Supply

X1 connector

Supported Interface

RS 232

Motor Power Connection Type

Three-Phase

Power Cable Lines

Three for power, One for protection

Terminal Connection

VT-100 terminal or a PC

Device Mounting

Back wall of control cabinet

Terminal Connection Screws

M5

Screw Tightening Torque

3Nm

Required Clearance

80mm at top and bottom

Airflow Direction

Bottom in, Top out

Degree of Protection

IP 10 (DIN 40 050 specs.)

Protection Against Solids

Objects with diameter more than 50mm

Positioning When Multiple Controllers

One with max output and high current level closest to supply unit.
