DDS02.1-W050-DL20-01-FW
The DDS02.1-W050-DL20-01-FW drive controller, produced by Bosch Rexroth Indramat, requires careful handling during transit to avoid tipping or dropping and must remain dry and free of load. Connection to the motor feedback should be achieved using the provided manufacturer's feedback cable, while the product's analog diagnostic outputs have a 10VDC voltage rating and 4mA current capacity. Notably, the start-lock mechanism doesn't force moving axis to a standstill and is activated by voltage application. The product features two control inputs with a voltage rating of 20VDC-30VDC and power of 1.5W. Connection to the power supply necessitates a 10mm2 earth connection, while fault clearance can be achieved through a reset key. Installation should be vertical, and the controller is prepared for up to 95% relative humidity and 25g/m3 absolute air humidity. The product has a one-axis positioning module, allowing connection to a DBS02.2 module, and should be checked for correct module insertion prior to commissioning. It also includes a U5 slot for a software module.
