S image of Digital MMC-D4

Digital MMC-D4

by Kollmorgen
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message

The Kollmorgen Digital MMC-D4 drive from the MMC Standalone Smart Drives series is an Industrial smart drive powered by a 32-bit RISC CPU with numeric coprocessor and equipped with 1 MB memory plus a 2 MB flash disk for firmware updates and data logging. It supports sourcing-only IEC Type 1 DC inputs at 24 VDC nominal (30 VDC max) and offers 8 DC outputs at the same voltage with 0.25 A max current per channel. Connectivity options include an RS232 secured port (up to 115200 baud), an RS232/RS485 user port with RTS/CTS hardware handshaking, and a 10/100Base-TX half-duplex Ethernet interface. A 3 V BR2032 lithium coin cell battery ensures time-of-day clock accuracy and data retention during power interruptions, making this smart drive ideal for reliable industrial automation applications.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Battery

3V BR2032 lithium coin cell

CPU

32-bit RISC with numeric coprocessor

DC Input Configuration

Sourcing only, IEC Type 1 (IEC 1131-2)

DC Input Voltage

24 VDC nominal, 30 VDC max

DC Output Voltage

24 VDC nominal, 30 VDC max

DC Outputs

8 channels

Ethernet Port

IEEE 802.3/802.3u, 10/100Base-TX, half duplex

Flash Disk

2 MB

Max Current per Output

0.25 A

Memory

1 MB

MMC/SD Drive Input Current

250 mA

MMC/SD Drive Input Voltage

20–30 VDC

PICPRO Port

RS232 secured, up to 115200 baud

Time-of-day Clock Accuracy

±1 s/day (25°C); +2/−12 s/day (ambient)

User Port

RS232/RS485, RTS/CTS, up to 115200 baud
