C image of DKR02.1-W200B-B | Main (Front Left)

DKR02.1-W200B-B

by Bosch Rexroth Indramat
$14,929.74 - $14,929.74
$14,929.74
$14,929.74 - $14,929.74
$14,929.74

In Stock, Ships 1 - 3 Days

Bosch Rexroth's DKR02.1-W200B-B is an ergonomically designed drive controller for the digital smart control of various Bosch Indramat motors, including AC main spindle, frameless, and linear motors. The controller is valued for its operational reliability and immense control range, with solid power delivery at a broad speed spectrum. It operates with a 3-phase 3 x 400 - 480v AC power source, at a rated current of 200 A. Features include an emergency shut-down, integrated mains contactor, and an incorporated fan for efficient cooling. The controller should be installed with a minimum 160 mm clearance above and below it to facilitate adequate airflow. Its bleeder resistor provides a maximum braking energy of 240 kWs and continuous power dissipation of 1.5 kW. The controller has five slots for plug-ins, utilizing an INTERBUS interface for command communication, and an ESM02.3 firmware module. With a protection rating of IP20, it operates optimally at up to +45°C, while dissipating 1800 W of heat.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Model

DKR02.1-W200B-B

Application

Control of various Rexroth Indramat motors

Power Source

3-phase 3 × 400 – 480 V AC

Operational Current

Rated Current of 200 A

Emergency Stop

Yes, equipped with an emergency stop shutdown switch

Cooling Method

Built-in fan, Air-cooled

Installation Requirement

Minimum clearance of 160 mm at the top and bottom

Brake Resistor

Max braking energy of 240 kWs, continuous power dissipation of 1.5 kW

Feedback

Digital Servo and Resolver feedback

Slots

5 slots (U1 to U5) for installing various plug-in modules

Interface

INTERBUS interface for command communication

Firmware Module

ESM02.3

Continuous Current

141/110 A

Continuous Power

55/42 kW

Heat Dissipation

1800 W

Operating Temperature

Normal operation at +45 degree Celsius

Protection Rating

IP20
