S image of DKR02.1-W200N-BA07-01-FW

DKR02.1-W200N-BA07-01-FW

by Bosch Rexroth Indramat
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The DKR02.1-W200N-BA07-01-FW by Bosch Rexroth Indramat is a drive controller primarily utilized to monitor and control electric motors. This device is specifically tailored for usage within machine tools and printing mechanisms, utilizing an air cooling system with a built-in blower. The controller supports a peak current of 200 Amperes and employs a digital servo motor feedback system with resolver feedback. The product is uniquely designed with an analog command communication interface. With a power voltage of 3-phase rated at AC 400 – 480 volts and a control voltage of 230 Volts AC, the load capacity greatly influences the power data. It's essential to remember that the unit's firmware must be ordered separately. Use outside approved parameters, including underwater, extreme temperatures, and abrupt temperature changes, is discouraged. The device operates optimally in temperatures 5-45 degrees Celsius, but can withstand a peak of 55 degrees at 80% nominal data. Storage and transit temperature range is -30 to 80 degrees Celsius.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Type

Drive Controller

Model

DKR02.1-W200N-BA07-01-FW

Application

Control/Monitoring of electric motors

Usage

Printing machines and NC machine tools

Cooling Method

Air-cooling by built-in blower

Peak Current

200 Amperes

Resistor

No standard bleeder resistor

Feedback System

Digital servo motor feedback with resolver

Communication Interface

Analog

Function Numeric Code

07

Version Func. Numeric Code

01

Firmware

Acquired separately

Load Capacity

Variable

Power Voltage

3-phase AC 400 – 480 volts ± 10%

Control Voltage

230 Volts AC, ± 10%

Operating Constraints

Underwater operations, extreme temperatures, abrupt temperature fluctuations

Operating Temperature Range (Nominal Specifications)

5 – 45 degrees Celsius

Peak Temperature (80 % Nominal Data)

55 degrees Celsius

Storage and Transit Air Temperature

-30 to 80 degrees Celsius
