S image of DKR02.1-W200N-BE45-01-FW

DKR02.1-W200N-BE45-01-FW

by Bosch Rexroth Indramat
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The DKR02.1-W200N-BE45-01-FW is a high-performing drive controller manufactured by Bosch Rexroth Indramat. Characterized by its operational precision, the device has a control voltage power of 0.2 kVA and functions at a system frequency of 50 - 60 Hz. A built-in blower achieves the cooling through the air channel, dissipating heat up to 1 kW at continuous current rating and switching frequencies of 4 and 8 kHz. The device operates optimally at elevation levels from 0 to 1000 m above sea level (ASL) and temperatures of 5 - 45 degrees Celsius. For installation, an M1-RAC 3 accessory kit weighing 1.7 kg is required. The device is fitted to meet an Ingress Protection rating of 20 (IP 20) in alignment with EN 60529 standards. It operates at a power voltage range of up to 380 Volts and a rated power voltage of 3 x AC 400-480 Volts, ± 10%.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Type

DKR02 Type Drive Controller

Model Number

DKR02.1-W200N-BE45-01-FW

Control Voltage Power

0.2 kVA

System Frequency

50 – 60 Hz

Heat Dissipation at Continuous Current Rating

1.6 kW

Cooling Mode

Air with built-in blower

Heat Dissipation through Air Channel

Up to 1 kW

Installation Elevation

0…1000 m ASL

Ambient Temperature

5 – 45 degrees Celsius

Accessory Kit

M1-RAC 3, Weight 1.7 kg

Derated Nominal Operating Specification

80 %

Max Operating Temperature at Derated Specification

55 degrees Celsius

Shipping/Storage Temperature Range

-30 to 80 degrees Celsius

Recommended Ambient Temperature

5 – 45 degrees Celsius

Ingress Protection Rating

IP 20

Power Voltage

0 … 380 Volts

Rated Power Voltage

3 x AC 400 – 480 Volts, ± 10 %
