C image of DKR02.1-W300B-BE76-01-FW | Main (Front Left)

DKR02.1-W300B-BE76-01-FW

by Bosch Rexroth Indramat
$13,823.90 - $13,823.90
$13,823.90
$13,823.90 - $13,823.90
$13,823.90

In Stock, Ships 1 - 3 Days

The DKR02.1-W300B-BE76-01-FW by Bosch Rexroth Indramat boasts optimal operational dependability alongside any corresponding electrical motors. This energy-efficient, maintenance-free drive controller is revered by international clients, delivering 55/43 kW of continuous power at a current of 141/110 A, influenced by its 4/8 kHz switching frequency. The controller, weights 104 kg, not including the auxiliary bleeder resistor, mounting frame, and accessories. When continuously operating, heat loss of 1800 W occurs, with 1200 W of it dissipated via the air channel using a blower unit. The unit's bleeder resistor can dissipate maximum energy of 240kWs. Equipped with a SERCOS interface, the model enables motor temperature control and brake monitoring. Safe operation requires compliance with specified conditions in the manual. The controller's main connection comes directly from 3-phase AC 400-480V power source with an AC 230V (+-10%) control voltage requirement. Housed under IP20 protection standard, the unit can safely operate between +5 to +45 degrees Celsius.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Model Number

DKR02.1-W300B-BE76-01-FW

Type

Drive Controller

Operational Reliability

Used with respective electric motors

Power Delivery

55/43 kW

Rated Current

141/110 A

Switching Frequency

4/8 kHz

Additional Features

Auxiliary Bleeder Resistor

Weight

Approximately 104 kg (excluding bleeder resistor, mounting frame, accessories)

Heat Loss

1800 W

Heat Dissipation

1200 W via air channel with blower unit

Bleeder Resistor Energy Dissipation

240 kWs

Communication

SERCOS interface

Installation Slot

U1 slot of the basic unit (DKR02.1-W300B)

Connections

Controls and monitors motor temperature and holding brake

Power Source

3-phase AC 400 – 480V

Control Voltage Requirement

AC 230V with ±10% augmentation

Enclosure Protection

IP20

Permissible Temperature Range

+5 to +45 degree Celsius.
