S image of DKR04.1-W300N-BE11-02-FW

DKR04.1-W300N-BE11-02-FW

by Bosch Rexroth Indramat
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The Bosch Rexroth Indramat-manufactured DKR04.1-W300N-BE11-02-FW drive controller is part of the Indramat DKR04 series. The unit's structure is comprised of a basic unit, a software module, a command interface card, and auxiliary plug-in modules. It features four types of command interface cards: the SERCOS interface, analog interface, Profibus interface, and INTERBUS interface. This module operates within an ambient temperature range of 5-45 degrees Celsius but can function up to 55 degrees Celsius with derating. With a protection category of IP 20, the drive controller boasts a power voltage of 0-380 Volts. The unit itself weighs 1.7 kilograms and can accommodate a rated current of 300 amps. It is designed for precise regulation with 2AD and ADF main spindle motors. The controller comes fully configured with firmware streaming all drive parameters. Ideal for numerically controlled machine tools, this unit assures precision in motion control.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Series

Indramat DKR04

Product Parts

Basic unit, software module, command interface card, auxiliary plug-in modules

Command Interface Card Types

SERCOS interface, analog interface, Profibus interface, INTERBUS interface

Design Type

Type 1

Protection Category

IP 20 per EN60529/ IEC529 standards

Ambient Temperature Range

5 to 45 degrees Celsius

Maximum Permissible Ambient Temperature with Derating

55 degrees Celsius

Controller Power Voltage

0 to 380 Volts

Weight

1.7 kilograms (with accessories kit)

Rated Current

300 amps

Compatible Motors

2AD and ADF main spindle motors

Additional Features

Integrated blower and heat sinks, digital servo and resolver feedback, broad speed range with constant speed, pre-configured drive controller, operating software

Storage and Shipping Temperature

-30 to 80 degrees Celsius

Application

Numerically controlled machine tools for precise motion control.
